Standing up Debezium Server for Postgres CDC

Eric Goldman
6 min read
Looking for a simpler solution? If you're reading this tutorial, you want to reliably stream changes out of your Postgres database. You’re looking into Debezium Server, but the single document (not docs!) isn’t answering your questions. I hit the same snag, and decided to save future developers similar toil by writting this guide. If you are looking for an easier, faster alternative to Debezium Server (that actually has a UI, can scale, and provides robust delivery guarantees), we built Sequin

Introduction

In this tutorial, you'll set up a complete CDC pipeline using Debezium Server (version 3.1) to capture changes from a PostgreSQL database and stream them directly to a webhook endpoint. Unlike the Kafka Connect runtime, Debezium Server provides a lightweight standalone application that can send change events directly to various destinations without requiring a Kafka cluster. Keep in mind that your trading out the overhead of Kafka for less scale, performance, and delivery guarantees.

What you'll learn:

  • How to configure PostgreSQL for logical replication
  • How to set up Debezium Server to capture database changes
  • How to stream these changes directly to a webhook endpoint
  • How to observe and work with CDC events from your database

Prerequisites

Before diving in, make sure you have:

Tool Version Notes
Java 17+ Required for running Debezium Server
PostgreSQL 14+ Running locally on default port 5432
curl/wget Any For downloading files
unzip Any For extracting the Debezium archive
psql Any (comes with PostgreSQL) For database operations
Web browser Any modern browser For viewing webhook results
Tip: To check if you have Java installed, run java -version in your terminal. For PostgreSQL, run psql --version. To follow along with this tutorial, I assume you’re using a default postgres setup (i.e. user postgres, etc.).

The Architecture

Here's what you're building:

  1. A PostgreSQL database with logical replication enabled
  2. Debezium Server running as a standalone application
  3. A webhook endpoint (using webhook.site) that receives the change events
  4. A simple "customers" table that you'll monitor for changes

When you're done, any change to the customers table will be captured by Debezium Server and sent as a JSON event to your webhook endpoint in real-time. This setup provides a foundation for building event-driven architectures without the complexity of managing a Kafka cluster.

Step 1: Configure PostgreSQL for logical replication

Ensure logical replication is enabled on your Postgres database:

psql -U postgres -c "SHOW wal_level;"

You should see logical in the output. If not, run the following commands to enable logical replication:

# Connect to PostgreSQL as the postgres user to modify system settings
sudo -u postgres psql -c "ALTER SYSTEM SET wal_level = logical;"
sudo -u postgres psql -c "ALTER SYSTEM SET max_replication_slots = 10;"
sudo -u postgres psql -c "ALTER SYSTEM SET max_wal_senders = 10;"

# Restart PostgreSQL to apply changes
# For Linux (systemd):
sudo systemctl restart postgresql

# For macOS (Homebrew):
brew services restart postgresql

These commands:

  • Set the Write-Ahead Log (WAL) level to "logical", enabling detailed change tracking
  • Configure replication slots to allow Debezium to track its position
  • Increase the number of WAL sender processes that can run simultaneously

Step 2: Create a database user and sample data

Debezium requires a PostgreSQL user with replication privileges and a table to monitor.

# Create a dedicated user for Debezium
psql -U postgres -c "CREATE ROLE dbz WITH LOGIN PASSWORD 'dbz' REPLICATION;"

# Create a sample database
createdb -U postgres inventory

# Create a sample table
psql -d inventory -U postgres <<'SQL'
CREATE TABLE customers (
  id SERIAL PRIMARY KEY,
  name TEXT NOT NULL,
  email TEXT UNIQUE,
  created_at TIMESTAMP WITH TIME ZONE DEFAULT CURRENT_TIMESTAMP
);

-- Set REPLICA IDENTITY to FULL to capture old values on updates and deletes
ALTER TABLE customers REPLICA IDENTITY FULL;

-- Grant necessary permissions to the dbz user
GRANT ALL PRIVILEGES ON DATABASE inventory TO dbz;
GRANT ALL PRIVILEGES ON ALL TABLES IN SCHEMA public TO dbz;
GRANT ALL PRIVILEGES ON ALL SEQUENCES IN SCHEMA public TO dbz;
SQL

The REPLICA IDENTITY FULL setting ensures that both old and new values are captured for updates and deletes, which is crucial for comprehensive change tracking.

Step 3: Download and set up Debezium Server

Debezium Server is a standalone application that connects to PostgreSQL and forwards change events to various sinks. Let's download and extract it:

# Download Debezium Server
curl -L -o debezium-server.zip https://repo1.maven.org/maven2/io/debezium/debezium-server-dist/3.1.1.Final/debezium-server-dist-3.1.1.Final.zip

# Extract the archive
unzip debezium-server.zip

# Navigate to the Debezium Server directory
cd debezium-server

You'll now have a directory structure containing:

  • run.sh - The script to start Debezium Server
  • lib/ - JAR files for Debezium and its dependencies
  • config/ - Configuration directory

Step 4: Create a webhook endpoint

To make it easy to standup and test Debezium Server, use webhook.site to quickly test webhook delivery:

  1. Open https://webhook.site in your browser
  2. A unique URL will be automatically generated for you (it looks like https://webhook.site/XXXXXXXX-XXXX-XXXX-XXXX-XXXXXXXXXXXX)
  3. Copy this URL - you’ll use it in the Debezium configuration
  4. Keep this browser tab open to see events as they arrive

Step 5: Configure Debezium Server

Create or modify the application.properties file in the config/ directory to tell Debezium where to connect and where to send events:

# Create or modify the configuration file
# PostgreSQL source connector configuration
debezium.source.connector.class=io.debezium.connector.postgresql.PostgresConnector
debezium.source.offset.storage.file.filename=data/offsets.dat
debezium.source.offset.flush.interval.ms=0
debezium.source.database.hostname=localhost
debezium.source.database.port=5432
debezium.source.database.user=dbz
debezium.source.database.password=dbz
debezium.source.database.dbname=inventory
debezium.source.database.server.name=inventory-server
debezium.source.schema.include.list=public
debezium.source.table.include.list=public.customers

# Set a unique replication slot name to avoid conflicts
debezium.source.slot.name=debezium_tutorial

# Topic prefix configuration
debezium.source.topic.prefix=inventory-server

# For capturing all changes including updates and deletes in full
debezium.source.tombstones.on.delete=false

# Initial snapshot configuration
debezium.source.snapshot.mode=initial

# HTTP sink (webhook) configuration
debezium.sink.type=http
debezium.sink.http.url=YOUR_WEBHOOK.SITE_URL_HERE
debezium.sink.http.timeout.ms=10000

# JSON formatter
debezium.format.value=json
debezium.format.key=json

Replace YOUR_WEBHOOK_URL_HERE with the URL you copied from webhook.site.

Step 6: Start Debezium Server

Now that everything is configured, start Debezium Server:

# Make the run script executable
chmod +x run.sh

# Start Debezium Server
./run.sh

Prepare for a wall of Java logs. You should see output indicating that Debezium Server is starting, with messages about Quarkus, the connector, and eventually reaching a "started" state.

Common startup messages include:

  • Quarkus initialization
  • PostgreSQL connector configuration
  • Connection to the database
  • Snapshot process (if this is the first run)
  • HTTP sink initialization

Step 7: Test the setup with database changes

Open a new terminal (keep Debezium Server running in the first one) and execute some changes to the customers table:

# Insert some test data
psql -d inventory -U postgres <<'SQL'
INSERT INTO customers (name, email) VALUES
  ('Alice Johnson', 'alice@example.com'),
  ('Bob Smith', 'bob@example.com');
SQL

# Update a record
psql -d inventory -U postgres -c "UPDATE customers SET email = 'alice.new@example.com' WHERE name = 'Alice Johnson';"

# Delete a record
psql -d inventory -U postgres -c "DELETE FROM customers WHERE name = 'Bob Smith';"

Step 8: Observe the results

Switch back to your webhook.site browser tab. You should see several POST requests that correspond to the database operations you just performed:

  1. Two insert events (one for each new customer)
  2. An update event (when you changed Alice's email)
  3. A delete event (when you removed Bob's record)

Each event contains a JSON payload with details about the operation and the data. For example, an insert event might look like this:

{
  "schema": { /* schema information */ },
  "payload": {
    "before": null,
    "after": {
      "id": 1,
      "name": "Alice Johnson",
      "email": "alice@example.com",
      "created_at": "2023-05-06T10:15:30.123456Z"
    },
    "source": {
      /* metadata about the event source */
      "db": "inventory",
      "table": "public.customers",
      "operation": "c",
      "ts_ms": 1683367230123
    },
    "op": "c",
    "ts_ms": 1683367230456
  }
}

The op field indicates the operation type:

  • c for create (insert)
  • u for update
  • d for delete
  • r for read (during initial snapshot)

For updates, both before and after fields are populated, showing the previous and new values.

How it works

Let's understand what's happening under the hood:

  1. PostgreSQL logical replication: The WAL settings enable PostgreSQL to maintain a log of changes that can be read by external processes.
  2. Debezium Server: Acts as a standalone change data capture service that:
    • Connects to PostgreSQL using the configured credentials
    • Reads the WAL stream to detect changes
    • Converts database changes to structured JSON events
    • Forwards these events to the configured sink (webhook in our case)
  3. Webhook endpoint: Receives HTTP POST requests containing the change events as JSON payloads.

Next steps and variations

Now that you have a working Debezium Server, here are some ways to expand and customize it:

Monitor multiple tables

To track changes from additional tables, adjust the debezium.source.table.include.list property in application.properties:

debezium.source.table.include.list=public.customers,public.orders,public.products

Transform events before sending

Debezium supports Single Message Transforms (SMTs) to modify events before they're sent. For example, to rename a field:

# Add this to application.properties
debezium.transforms=rename
debezium.transforms.rename.type=org.apache.kafka.connect.transforms.ReplaceField$Value
debezium.transforms.rename.renames=email:contact_email

Conclusion

You've successfully set up Debezium Server to capture and stream PostgreSQL changes to a webhook endpoint. This foundation can be extended to build robust event-driven architectures, real-time data pipelines, and more.
